Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: GELON
  • Model Number: GN-510M
  • Type: 18650 cell
  • Nominal Voltage: hydraulic sealing machine
  • Size: cylindrical cell
  • Pressure Gauge:: 0-3500 psi (0-250 kg/cm^2)
  • Driving Force:: Manual hydraulic pressing up to 5T
  • application: Cylinder battery machine

Packaging & Delivery

Packaging Details standard export package for cylindrical cell machine
Delivery Time within 15 working days for cylindrical cell crimping machine

Quick details
1.hydraulic crimper
2.for sealing all types of cylinder cases
3.full set of service

Product Description



Desk-top Hydraulic Sealing Machine for Cylindrical Cases (Optional: 26650, 18650, CR123, AA, AAA etc) - GN-510M series



 introduction:



GN-510M is a compact hydraulic crimper for sealing all types of cylinder cases in battery R&D labs. The compact body design allows it to be easily placed inside a glove box and thus preventing contamination of the electrolyte materials during cell assembly. Simple operation with safety protection feature allows customers to master the sealing procedure within 5 minutes.





Sealing Machine for Cylindrical Cases spec:







Driving ForceManual hydraulic pressingup to 5T
Pressure Gauge0-3500 psi (0-250 kg/cm^2)
BodyStainless Steel
Crimping DiesSix standard die selectable: CR123 /18650 / 26650 / 32650 / AA /AAA
ComplianceCE certified
Warranty
  • One year limited with lifetime support
  • Parts rusted without regular cleaning and maintenance are not covered
Product Dimensions320mm(L) x 240mm(W) x 400mm(H)
Application Notes
  • Customized die for other cylindrical cell types is available upon request
  • It is necessary to groove the opening end of the cylindrical case by using the GN-500 grooving machine before sealing the cap
  • Each type of cylinder cell can only be sealed specifically by certain model of equipment.
  • We will also provide free cylindrical cases along with the equipment for your operation practice.
Net Weight26 kg (58 lbs)





Packaging & Shipping









Our Services



1.)full set of lithium battery materials,including :



LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Alumimun foil,copper foils,battery separator,etc.



2.)full set of lithium battery equipments,for example:



mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.



3)full set of lithium battery technology



we can design the laboratory and production line,according to customer's request.
