Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Gelon
  • Model Number: GN-400 calendaring machine
  • roller size: 400*400
  • Voltage: 380V
  • power: 7.5KW
  • Outside size: 1750*750*1750
  • Weight: 3300Kg
  • Working principle: Machinery rolling
  • Application: lithium ion battery production line

Packaging & Delivery

Packaging Details wooden box with inside protection
Delivery Time within 20days

Single sheet calendaring machine for lithium ion battery production line 400mm type

I,WorkingPrinciple:

The equipment consists of high hardness pressure reducer motor-driven roller, mechanical adjustment roller gap, pole piece will be made Compression molding increased the density of the pole piece of quality. Using the industry's leading heating system and PID temperature control system, rapid heating, uniform temperature control accuracy, when the temperature reached, it can thermostat automatically.

II,Technical Parameters:

1.Rated voltage/power: 3phase 380v/7.5kw.

2.Pressure roller size: Φ400mm×400mm.

3.The roll surface hardness:HRC62-C64.

4.Cylindrical roller degree: ±0.005mm.

5.Effective gap: 0-2 mm (adjustable).

6.Working speed: stepless speed, line speed 0-1.5 m/min (adjustable).

7.The working width: 0-- 400mm.

8.The roll surface quenching depth: 12-14mm.

9.Net weight: approx3300kg

10.Overall size: approx 1750 (L) ×750(W) ×1750(H) mm.











In 2013, our Bolivia Project  for batery production line has completed successfully. Bolivia  president and goverment gave a full support and confirm. And our next project for Indonisia will start this year.



More information you can visit our website:

Turn-key Project of Li Battery  (Lab, Mobile, EV) Production Line

Video Link:
http://v.youku.com/v_show/id_XNjg5ODczMTg0.html

Coating Process:
http://v.youku.com/v_show/id_XNjg5ODc3OTI4.html



Any questions, pls contact us:
